GT SONIC-D3 100W 40kHz Ultrasonic Cleaner 3L 6L 9L 13L Capacity Optional

Brand Name	GT SONIC
Model Number	GT SONIC-D3
MOQ	1pc
Price	Negotiable
Packaging Details	Standard packing: carton packing or customized
Payment Terms	L/C, T/T

GT SONIC-D3 3L Ultrasonic Cleaner Applications for Optical, Laboratory and Small-Parts Workflows

Optical Frames

Everyday frames collect oil, dust and handling residue around edges and joints; the 3 L chamber keeps frames fully supported during a routine cycle.

Optical

Laboratory Glassware

Beakers, tubes and vials can be cleared of ordinary residue, subject to the item maker’s care instructions and a fit check before immersion.

Laboratory

Dental Tools

Instruments and handpieces can be placed beside the tank to judge scale, then refreshed in a short controlled cycle between appointments.

Dental

PCB-Compatible Parts

For compatible PCB assemblies and electronic parts, the Normal and Soft power control helps match intensity to sensitive boards and connectors.

Electronics

Hardware And Fasteners

Machined parts, fasteners and small metal components fit the stainless tank for routine degreasing and residue removal before assembly or inspection.

Hardware

Jewelry Batches

Jewelry batches can be cleaned in short cycles when their materials, adhesives and stones are confirmed ultrasonic-safe by the maker.

Jewelry

Check GT SONIC-D3 Pricing

GT SONIC-D3 Ultrasonic Cleaner Performance, Safety and Reliability

Cleaning Action

40 kHz ultrasonic power with Normal and Soft modes

40 kHz Ultrasonic Cleaning

40 kHz ultrasonic operation moves cleaning liquid around accessible crevices, targeting ordinary residue rather than promising scratch-free or sterile results.

Normal and Soft Power Control

Normal and Soft modes resolve the cleaning blind spot: Full power for sturdy metal parts, Soft power for more delicate compatible items.

Degas Function

The degas mode removes dissolved gases from fresh cleaning liquid, improving cavitation and cleaning efficiency before batch work.

Heating Function

The 100 W heater improves cleaning effect on grease and stubborn residue, with the temperature chosen according to the object and solution.

Structure & Material

A stainless-steel benchtop tank built for daily workflows

Stainless Steel Tank

The stainless steel tank is designed for daily water and solution use; fill it to the appropriate level and keep electrical parts dry.

3 L Benchtop Chamber

Tank size 240×140×100 mm gives optical frames, tools and small batches room to move, with 6 L, 9 L and 13 L capacities optional in the D series.

User-Friendly LED Display

The LED panel shows time and temperature at a glance, so operators can confirm settings before every cycle.

Compact Benchtop Body

Overall size 270×170×140 mm and a 3.6 kg net weight let the D3 sit on a bench or workstation without taking over the room.

Control & Safety

Adjustable, repeatable controls for consistent results

1–99 Minute Timer

Time is adjustable from 1 to 99 minutes; start with the shortest appropriate setting and inspect the item before repeating a cycle.

0–80 °C Adjustable Heating

Heating temperature is adjustable from 0 to 80 °C, so heat-sensitive items can be cleaned cool while metals benefit from warmth.

Clear Button Sequence

The D3 panel keeps its own normal/soft and degas controls, so operators follow one consistent sequence instead of borrowing settings from other models.

Wide Voltage Support

AC 100–120 V 60 Hz and AC 200–240 V 50 Hz variants cover major destination markets; confirm the plug standard with the sales team.

Buying Confidence

Backed by GT SONIC manufacturing and certification

Certified for Global Markets

CE, FCC and RoHS certificates support distribution across major markets for this benchtop model.

12-Month Warranty

The D3 ships with a 12-month warranty and carton or customized packing for retail and distributor channels.

Stable Production Capacity

Supply ability of 3,000 pcs per day keeps reorders predictable for optical shops, laboratories and equipment dealers.

OEM / ODM Support

Logo, packaging, plug and capacity variants can be confirmed with GT SONIC for private-label and project requirements.

Request GT SONIC-D3 Specifications

GT SONIC-D3 100W 40kHz Ultrasonic Cleaner Specifications & D-Series Capacity Matrix

Model	GT SONIC-D3
Tank Capacity	3 L (6 L / 9 L / 13 L optional)
Ultrasonic Power	100 W
Heating Power	100 W
Ultrasonic Frequency	40 kHz
Timer	1–99 minutes
Heating Temperature	0–80 °C
Cleaning Mode	Normal / Soft, Degas
Tank Size (L×W×H)	240 × 140 × 100 mm
Overall Size (L×W×H)	270 × 170 × 140 mm
Power Supply	AC 100–120 V 60 Hz / AC 200–240 V 50 Hz
Net Weight	3.6 kg
Certificates	CE, FCC, RoHS
Warranty	12 Months

D-Series capacity and power matrix:

Model	Capacity	Ultrasonic	Heating	Tank Size
D3	3 L	100 W	100 W	240 × 140 × 100 mm
D6	6 L	150 W	300 W	300 × 155 × 150 mm
D9	9 L	200 W	300 W	300 × 240 × 150 mm
D13	13 L	300 W	400 W	330 × 300 × 150 mm

Request Specification Sheet

GT SONIC-D3 Ultrasonic Cleaner: Easy to Use, Easy to Understand

Three-Step Use Guide

1. Fill — Fill the 3 L tank to the appropriate level with water or a solution approved for the item, and keep the electrical body and controls dry.

2. Place and select — Place compatible items without crowding, then set the 1–99 minute timer, mode and temperature. For a new material or coating, begin conservatively.

3. Remove and dry — When the cycle ends, lift out the item, rinse if needed and dry it, then empty and wipe the tank after use.

What Can It Clean?

Optical frames Laboratory glassware Dental tools PCB-compatible parts Hardware & fasteners Jewelry batches

Suitability depends on construction, adhesives, finish and the maker’s care guidance.

Operation Tips

Check the item’s care instructions first Avoid porous stones and fragile settings No medical sterilization claims Remove loose or damaged pieces Do not overload the tank Test cleaning liquids and heat on the material

Get Best Price

Frequently Asked Questions About GT SONIC-D3 Ultrasonic Cleaner

What makes GT SONIC-D3 different from a basic eyeglass cleaner?

GT SONIC-D3 is a benchtop cleaner built around Normal and Soft power modes, a degas function and adjustable heat. Verified numbers are listed on the page — 100 W ultrasonic, 40 kHz, a 240×140×100 mm tank and a 1–99 minute timer — instead of a generic ‘deep clean’ claim.

Can I use water only with this 3 L cleaner?

Water can suit light routine dirt on compatible items. Stubborn residue may need an item-safe, water-based solution; always follow the item and cleaner instructions.

Which items should stay out of the tank?

Keep non-waterproof electronics and items with uncertain coatings, adhesives, porous stones or fragile settings out until their makers confirm ultrasonic compatibility.

How long should one cycle run?

Use the model-specific 1–99 minute timer. Start with the shortest appropriate setting and inspect the item before repeating a cycle.

How do I choose between the D3 and a larger D-series model?

Start with the largest item to be cleaned, the number of items per batch and how much control you need. The D3 covers 3 L at 100 W; D6, D9 and D13 models scale the tank and power for 6 L, 9 L and 13 L workloads.

What should a distributor confirm before placing an order for GT SONIC-D3?

Confirm the exact power and frequency variant, destination voltage and plug, accessories, carton pack and model label. Ask for applicable certificates (CE, FCC, RoHS) and a sample or signed specification sheet.
